Item no: 26606ACA

TIPCAM1 RUBINA 0°, OPAL1 NIR/ICG, 4K 3D

Quantity:

Product details

TIPCAM®1 Rubina® – The New 4K-3D NIR/ICG Videoendoscope


  • Automatic horizon control for better orientation and handling
  • Available with 0° and 30° directions of view
  • Easy toggle from 3D to 2D
  • OPAL1® NIR/ICG visualization modes: Overlay, Monochromatic and Intensity Map
  • 4K image chain
  • Technical details
  • Documents & Films
  • Product group / field of application
Image sensor resolution4K
Direction of view
Outer diameter10.3 mm
Working length317 mm
Fluorescence imaging (NIR/ICG)Yes, in conjunction with POWER LED Rubina®
Connection4U-Line
Weight420 g
Cable length300 cm
Cable routingStraight
Frame rate50 / 60 Hz
Image sensor typeCMOS
Number of image sensors2
Zoom functionYes, digital
Camera head buttons3 Buttons, 2 freely programmable
AutoclavableYes
H2O2 (hydrogen peroxide)Yes
S-TechnologiesCLARA, CHROMA, SPECTRA A + B
Degree of protection in conjunction with the IMAGE1 S™ camera control unitCF-Defib
Scanning methodProgressive scan
BrandTIPCAM®1
