| System interface | C-MAC® |
| Screen diagonal | 3.5" |
| Resolution | 640 x 480 px |
| Wide angle display | 160° |
| IP protection class | IPX8 |
| Rechargeable battery, battery type | Chargeable Li-ion battery, exchangeable |
| Storage medium for documentation | Permanent memory |
| Battery operating time max. | 90 min |
| Power Management | Capacity indicator of chargeable Li-ion battery |
| Adjustability | Movable via two rotation axes |
| Screen width | 100 mm |
| Screen height | 90 mm |
| Length | 120 mm |
| Width | 100 mm |
| Depth | 50 mm |
| Weight | 225 g |
| Input voltage | 3.7 V |
