| Power bipolar max. | 200 Watt |
| Power unipolar max. | 400 Watt |
| Connection socket for bipolar instruments | 1 x 2-pin US type, 2 x KARL STORZ |
| Connection socket for unipolar instruments | 1x 3-pin US-type connector, 1x 5 mm connector KARL STORZ, 1x 4 mm connector (foot-switched) |
| Connection socket for neutral electrode | 1x 2 pin |
| Power supply | 220 – 240 VAC |
| Output frequency | 0.35 / 1 MHz |
| Line frequency | 50/60 Hz |
| Rated resistance bipolar | 75 Ohm |
| Rated resistance unipolar | 100 Ohm |
| Control via touch screen | Yes |
| Bipolar sockets expandable to | 2 |
| Connection socket for footswitch | 2 |
| KARL STORZ / Erbe VIO – connection socket bipolar | 2 |
| BiVascularSafe mode | No |
| Can be integrated into OR1™ | With SCB control WU300 |
| System requirements OR1™ integration | SCB R-UI software, Release 20090001-46 or higher |
| Certification | With CE certification |
| Brand | AUTOCON® |
| Width | 447 mm |
| Depth | 457 mm |
| Height | 177 mm |
| Weight | 12.5 kg |
