Item no: WD310
AIDA® C stands for the comprehensive implementation of all medical documentation requirements arising in surgical procedures.
The system enables flexible adaptation to the needs of various specialities and thereby allows for the highest degree of customization. The system seamlessly integrates into existing infrastructures and can exchange data with other systems using common standard interfaces, e.g., hospital information and archiving systems.
| Image formats | BMP, PNG, JPEG |
| Video formats | MPEG-4 |
| 3D image display | No |
| Resolution | SD, HD, FULL HD |
| Operating system | Windows 10 IoT |
| Remote service | Yes |
| DVI-D output | 1 |
| Power supply | (AC)/ 100 – 240 VAC |
| Line frequency | 50/60 Hz |
| Width | 305 mm |
| Height | 74.5 mm |
| Depth | 355 mm |
| Weight | 6 kg |
| Wipe disinfection | Yes |
| Interfaces | DICOM, network drive, FTP |
| Voice control | Yes |
| WLAN adaptor | Yes, IEEE 802.11ac |
| Electrical protection class | Protection class 1 |
| IP protection class | IP20 |
| Hard drive capacity | 2.5", 1 TB SATA 3 |
| Audio | Capture and output |
| USB 3.0 | 5 |
| USB 2.0 | 4 |
| HDMI 2.0 input | 1 |
| DisplayPort 1.2a output | 2 |
| LAN Ethernet 10, 100, 1000 | 2 |
| COM RS232 | 3 |
| ACC | 4 |
| LEMO 5-pin for footswitch | 1 |
| POAG connection | 1 |
| Electrical protection class | I |
